Stainless Steel Sheet Grade 304

Stainless Steel Sheet Grade 304

Stainless steel sheet Grade 304 is ideal due to its high tensile strength, ease of roll forming or bending, rust resistance, and machining capabilities.

Overview

304 stainless steel sheet

Flexible Stainless Steel Sheet Grade 304 Sheet is known to be the most widely used and flexible austenitic form of stainless steel. It contains 8% nickel and 18% chromium, making it ultra-resistant to corrosion and oxidation. It is also highly durable and can be fabricated with ease. Cleaning the metal is also easy, and it is available in various appearances and finishes.


Features

304 stainless steel sheet and the plate feature

Flexible 304 stainless steel sheet and the plate is ideal due to its high tensile strength, ease of roll forming or bending, rust resistance and machining capabilities. 304 sheet is cost-effective and the most popular and economical of the stainless steels and is versatile for most applications where durable support and corrosion resistance are required. Stainless steel sheets and plates also offer excellent load-bearing properties, high corrosion resistance, excellent durability, high strength to weight ratio, good thermal and electrical conductivity, ease of fabrication, ease of cleaning and high finish. 304 stainless steel sheet has good resistance to many chemical corrosives and to industrial atmospheres and marine environments. 304 stainless steel sheet may be slightly magnetic in operation and is not heat treatable. Easy and simple to maintain as no surface treatment is necessary



Flexible 304 stainless steel sheet is an outstanding metal for auto trim and molding, kitchen equipment, wheel covers, truck bodies, exhaust manifolds, storage tanks, pressure piping, and vessels.


Specifications

Product NameStainless Steel Sheet Grade 304
Materials201/202/301/304/304L/316/316L/410/420/430
TechniqueCold Rolled, Hot Rolled
Thickness0.20-18.0mm
Width6-1500mm
LengthAs per your requirement
FinishEmbossment, drawbench, polishing, frosting, copper surface, defend bath surface, color, elevator surface and so on.
StandardASME, ASTM, EN ,BS,GB,DIN, JIS etc
Materialsstainless steel 304
ApplicationPetroleum, chemistry, electricity, paper making, alkali making, irrigation works, automotive, salt, medicine, food, and public facilities
PackageStandard export seaworthy package
Delivery TimeDepends on quantity, usually 5-10 days after receiving deposits
Payment termTT, L/C, DP or Negotiable
Container Size20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High)
NoteWe are so able to produce another standard as per the clients' requirements


Physical property:

Strength of extension: σb ( MPa )≥520

Yield strength σ0.2 (MPa) ≥205

Elongation: σ5(%)≥40

Percentage reduction of area: Ψ(%)≥60


Stainless steel 304 Grade: 0Cr18Ni9 (0Cr19Ni9)
Chemical Components:
CSiMnCrNiSP
≤0.08≤1.0≤2.018.0~20.08.0~11.0≤0.030≤0.045



Uses

304 SS sheet and plate applications

Grade 304 has a lower carbon content than 302 and 304/304L than the direct grade 304. 304 and 304L types have very good stretchability and excellent corrosion resistance in chemical, textile, petroleum, and food industry exposures. At the same time, 304 stainless steel sheet has an aesthetically pleasing surface and a wide range of possibilities.

Food and beverage: Category 1 and 2 tableware

Pressure-bearing applications: cabinets, indoor plumbing, water heaters, boilers, bathtubs

Aerospace Structures

Cryogenics: food industry

Hygienic applications: medical appliances, chemical

Building structures: building materials, agriculture

Automotive components

Marine components

Stainless steel sheet Grade 304

Stainless steel sheet Grade 304

Stainless steel sheet Grade 304

Stainless steel sheet Grade 304


Stainless Steel Sheet Grade 304 Stainless Steel Sheet Grade 304 Stainless Steel Sheet Grade 304
